Glass-to-metal Hermetic Seals Catalog. Glass to Metal Hermetic Feedthroughs /Seals /Headers /Connector is also called Glass insulator.They are one of the most critical components for seal assemblies. Dielectrics and supporting materials are made of glass with low dielectric constant and low dielectric loss. Both inner conductor(pin/contact) and outer conductor(ferrule/outer ring) are made of Kovar alloy and sintered at high temperature. The surface is plated with gold. Inner conductor has a variety of termination styles such as gold wire bonding, soldering and mating etc. Glass insulators are small, lightweight, hermetic, reliable and have been widespread in electronics manufacturing industries recent years.
mmW Between Sereis Adapter Catalog. K2.92mm, 3.5mm, 2.4mm, 1.85mm, 1.0mm female to female, male to male, female to female adapters.
Waveguide to Coax Adapters Catalog. Coaxial Type: N, TNC, SMA, 3.5, 2.4, SMP, SSMP. Wave-guide: BJ84 ~ BJ500(WR112~WR18). Structure: end launch, right angle launch. Frequency Range: 6.5~50GHz. Material: Aluminuim Copper
Company Profile. Xi\'an Elite Electronic Industrial Co., Ltd. is a national high-tech enterprise that specializes in R & D, manufacture and sales of RF connectors, adapters, cable assemblies, wave-guide products, glass-to-metal hermetic connectors, micro d-sub, microwave rotary joints and other microwave components. These RF/Microwave products are widely used in aerospace, aviation, navigation, 5G, satellite, communications, antennas and other important electrical systems.
ASMP Catalog. ASMP is a new blind mate RF connector which have the same structure and using method with SMP. The outline dimension is about 22% larger than SMP, the transmitted power is almost 30%~50% higher. It meets well board to board connection, modular intensive mounting and high power requirements situations. Male SMP connector have two kinds of interface full detent structure and unthreaded hole, female connector only have one interface, which can be mated with every kind of male connector.
CSMP Catalog. CSMP is a miniature push-on RF coaxial connector, which have the characters of small volume(compared with SSMP),light weight,wide working broadband,etc. Apply for the couple usage of board to board connectors,for the situation of modular intensive mounting,and the plug has two interface form with full detent and unthreaded hole.
SSMP Catalog. SSMP is a miniature push-on RF coaxial connector, which have the characters of small volume(compared with SSMP), light weight,wide working broadband,etc. Apply for the couple usage of board to board connectors ,for the situation of modular intensive mounting,and the plug has two interface form with full detent and unthreaded hole.
